Özellikler
| Weight | 700 g |
|---|---|
| Dimensions | 206 × 135 × 30.1 mm |
| Form-factor |
Panel |
| Display Size (inch.) |
7.0" |
| Resolution |
1024*600 |
| CPU |
Cortex-A53 (Raspberry Pi) |
| FLASH |
8GB |
| RAM |
1GB |
| Brightness (cd/m²) |
500 |
| Bluetooth |
Onboard Bluetooth |
| WiFi |
Onboard WiFi |
| 4G |
Yes, Not mount by default |
| Ethernet |
1x LAN 100M |
| Camera |
Yes, Not mount by default |
| USB |
1x USB 2.0 OTG, 2x USB 2.0 HOST |
| GPIO |
Opto-Isolated GPIO, 4Input,4 Output, Can drive up 500mA current every Channel at most (external power source) |
| RS485 |
1 Channel ,The RS485 multiplex with the RS232_1. That means customer can’t use RS232_1 and the RS485 at the same time. |
| RS232 |
2x RS232 |
| Buzzer |
Yes |
| Power Consumption |
7W Typical |
| OS |
Debian |
| External storage |
2 TF card slots One TF Card slot design for Lite version that has no eMMC. The other one TF Card slot design for storage expansion |
| Touch Screen |
5-Point Capacitive |
| Power Input |
6~36V DC |
| Working Temperature |
-20°C ~ 70°C. |
| Mounting Method |
Panel Mounting & VESA |
